疏水性硅基标签辅助的肽醇液相合成

doi:10.6023/cjoc202503021

摘要/Abstract

开发了一种新型疏水性硅基标签((氯亚甲基)双(1,4-亚苯基))双(氧))双(叔丁基二甲基硅烷)(CBTBS), 用于辅助液相合成肽醇. 通过采用环境友好型溶剂乙酸乙酯(EA)替代具有生殖毒性的N,N-二甲基甲酰胺(DMF), 并使用3-巯基-1-丙烷磺酸钠(Mps)与1,8-二氮杂二环十一碳-7-烯(DBU)的协同脱保护体系(取代传统受管制的哌啶试剂). 该策略不仅能够高效且便捷地去除富烯加成物等副产物, 还实现了Gramicidin A片段的高效合成(粗品收率>80%). 与传统固相合成相比, 该方法的过程质量强度(PMI)大幅降低, 为肽醇的绿色合成开辟了一条高效、可持续的新途径.

关键词: 疏水性硅基标签, 肽醇, 液相合成, 绿色

This study presents the development of a novel hydrophobic silicon-based tag, ((chloromethylene)bis(1,4-phen- ylene))bis(oxy))bis(tert-butyldimethylsilane) [CBTBS], for facilitating the liquid-phase synthesis of peptide alcohols. By replacing the reproductive-toxic solvent N,N-dimethylformamide (DMF) with the environmentally friendly ethyl acetate (EA) and implementing a synergistic deprotection system using sodium 3-mercapto-1-propanesulfonate (Mps) and 1,8-diazabicyclo- [5.4.0]undec-7-ene (DBU) (substituting the traditionally regulated piperidine reagent), this strategy enables efficient and convenient removal of byproducts such as fulvene adducts. Additionally, it achieves high-efficiency synthesis of the Gramicidin A fragment with a crude yield exceeding 80%. Compared with conventional solid-phase synthesis, this method significantly reduces the process mass intensity (PMI), thereby providing an efficient and sustainable new pathway for the green synthesis of peptide alcohols.

Key words: hydrophobic silica-based tag, peptide alcohol, liquid phase synthesis, green

引用此文

程蓉, 钱伊依, 徐元强, 苏贤斌. 疏水性硅基标签辅助的肽醇液相合成[J]. 有机化学, 2025, 45(12): 4433-4442.

Rong Cheng, Yiyi Qian, Yuanqiang Xu, Xianbin Su. Liquid-Phase Synthesis of Peptide Alcohol Assisted by a Hydrophobic Silica-Based Tag[J]. Chinese Journal of Organic Chemistry, 2025, 45(12): 4433-4442.

导出引用 EndNote|Reference Manager|ProCite|BibTeX|RefWorks

分享此文

图/表 11

图式1. 传统固相合成肽醇及疏水性硅基标签CBTBS

Scheme 1. Traditional solid-phase synthesis of peptidols and hydrophobic silicon-based tag CBTBS

图式2. CBTBS的合成以及接入第一个氨基醇

Scheme 2. Synthesis of CBTBS and coupling of the first amino alcohol

图式3. Fmoc脱保护及副产物的去除

Scheme 3. Fmoc deprotection and by-product removal

Reagent	DBF/Fulvene adduct^a	Washing solvent	Removal rate^b/%	Yield^c/%
Piperidine	6∶94	HCl aq	100	89
Pyrrolidine	16∶84	HCl aq	100	76
DBU/Mps	>99	K₂CO₃ aq	100	98

表1. 哌啶、四氢吡咯和Mps捕获DBF的效果对比

Table 1. Comparison of DBF capture performance among piperidine, pyrrolidine and Mps

Reagent (mmol)	DBU/mmol	DMSO/EA (volume ratio)	DBF/Fulvene adduct^a	Washing solvent	Removal rate^b/%	Yield^c/%
Mps (5)	3	1∶1	>99	K₂CO₃ (aq.)	100	98
Mps (5)	1	1∶1	>99	K₂CO₃ (aq.)	100	98
Mps (5)	1	3∶7	>99	K₂CO₃ (aq.)	100	98
Mps (5)	1	2∶8	>99	K₂CO₃ (aq.)	100	98
Mps (2)	1	2∶8	>99	K₂CO₃ (aq.)	100	98

表2. Fmoc脱保护反应条件优化

Table 2. Optimization of Fmoc deprotection reaction conditions

图1. 偶联模板反应

Figure 1. Coupling template reaction

Entry	Coupling reagent (mmol)	Conversion^a/%	Yield^b/%
1	HATU (1.5)	100	93
2	DIC (1.5)	100	90
3	EDC•HCl (1.5)	100	98
4	EDC•HCl (1.1)	100	98
5	EDC•HCl (1.0)	96	92

表3. 缩合试剂的选择

Table 3. Selection of condensing reagents

图式4. 标签辅助液相合成Gramicidin A片段

Scheme 4. Tag-assisted liquid phase synthesis of Gramicidin A fragment

SPPS		Tag-assisted LPPS
Material	Dosage/kg	Material	Dosage/kg
CTC Resin (1 mmol/g)	1.00	CBTBS	0.46
Fmoc-AA-OH	8.32	Fmoc-AA-OH	2.74
Coupling reagent	5.47	Coupling reagent	1.09
DMF	64.23	EA	2.71
Piperidine	5.89	DBU/Mps	3.08

表4. 合成Gramicidin A片段物料消耗对比

Table 4. Comparison of material consumption for synthesizing Gramicidin A fragment

Synthetic method	Purity (HPLC)/%	Yield/%
SPPS	70	95
Tag-assisted LPPS	65	80

表5. SPPS和Tag-assisted LPPS合成Gramicidin A片段的收率与纯度对比

Table 5. Comparison of yield and purity in Gramicidin A fragment synthesis: SPPS vs Tag-assisted LPPS

图2. SPPS与Tag-assisted LPPS合成1 mol Gramicidin A片段的PMI对比

Figure 2. Comparison of PMI of 1 mol Gramicidin A fragment synthesized by SPPS and Tag-assisted LPPS

参考文献 26

[1]	(a) Drucker D. J. Nat. Rev. Drug Discovery 2020, 19, 277. doi: 10.1038/s41573-019-0053-0
	(b) Drucker D. J.; Dritselis A.; Kirkpatrick P. Nat. Rev. Drug Discovery 2010, 9, 267. doi: 10.1038/nrd3148
	(c) Peng W.; Cheng R.; Liu H.; Liu D. M.; Su X. B. Chin. J. Org. Chem. 2024, 44, 2876. (in Chinese) doi: 10.6023/cjoc202403015
	(彭伟, 程蓉, 刘豪, 刘冬梅, 苏贤斌, 有机化学, 2024, 44, 2876.) doi: 10.6023/cjoc202403015
	(d) Liu H.; Liu D. M.; Sun H. T.; Xia C.; Su X. B. Chem. J. Chin. Univ. 2024, 45, 9. (in Chinese)
	(刘豪, 刘冬梅, 孙浩田, 夏超, 苏贤斌, 高等学校化学学报, 2024, 45, 9.)
	(e) Wang B.; Cai X. D.; Xiao J. X. Acta Chim. Sinica 2024, 82, 367. (in Chinese) doi: 10.6023/A23100448
	(王博, 蔡向东, 肖建喜, 化学学报, 2024, 82, 367.) doi: 10.6023/A23100448
	(f) Yin H.; Chen X. T.; Fu X. Y.; Ma Y. N.; Xu Y. M.; Zhang T.; Liang S.; Du S.-S.; Qi Y. K.; Wang K. W. Acta Chim. Sinica 2022, 80, 444. (in Chinese) doi: 10.6023/A21120580
	(尹昊, 陈西同, 付邢言, 马艳楠, 徐以梅, 张特, 梁帅, 杜姗姗, 齐昀坤, 王克威, 化学学报, 2022, 80, 444.) doi: 10.6023/A21120580
[2]	Qi Y. K.; Zheng J. S.; Liu L. Chemistry 2024, 10, 2390.
[3]	Cameron A. J.; Davison E. K.; An C.; Stubbing L. A.; Rod Dunbar P.; Harris P. W. R.; Brimble M. A. J. Org. Chem. 2020, 85, 1401. doi: 10.1021/acs.joc.9b02348 pmid: 31755712
[4]	(a) Tailhades J.; Gidel M. A.; Grossi B.; Lécaillon J.; Brunel L.; Subra G.; Martinez J.; Amblard M. Angew. Chem., Int. Ed. 2010, 49, 117. doi: 10.1002/anie.200904276 pmid: 2479100
	(b) Crease R. P. Science 1989, 246, 883. pmid: 2479100
[5]	Cornell B. J. Bioenerg. Biomembr. 1987, 19, 655. pmid: 2447070
[6]	Du Y. Y.; Shi J. Y.; Duan R.; Tsim K. W. K.; Shen L.; Zhang N.; Wang B. Biomater. Adv. 2022, 140.
[7]	Ji Z. W. Ph.D. Dissertation, Jiangnan University, Wuxi, 2020. (in Chinese)
	姬中伟, 博士论文, 江南大学, 无锡, 2020).
[8]	Chalamaiah M.; Yu W. L.; Wu J. P. Food Chem. 2018, 245, 205. doi: S0308-8146(17)31726-0 pmid: 29287362
[9]	Lephart E. D. Ageing Res. Rev. 2016, 31, 36. doi: 10.1016/j.arr.2016.08.001 pmid: 27521253
[10]	Moulin A.; Martinez J.; Fehrentz J. A. J. Pept. Sci. 2007, 13, 1. pmid: 16998827
[11]	Ferrer-Gago F. J.; Koh L. Q.; Lane D. P. Chem.-Eur. J. 2020, 26, 379. doi: 10.1002/chem.201903965 pmid: 31609031
[12]	Vijayan V. M.; Shenoy S. J.; Muthu J. Mater. Sci. Eng., C 2017, 76, 490. doi: 10.1016/j.msec.2017.03.125
[13]	Ferrer-Gago F. J.; Koh L. ChemPlusChem 2020, 85, 641. doi: 10.1002/cplu.201900749 pmid: 32237227
[14]	(a) De Zotti M.; Biondi B.; Peggion C.; Formaggio F.; Park Y.; Hahm K. S.; Toniolo C. Org. Biomol. Chem. 2012, 10, 1285. doi: 10.1039/C1OB06178J
	(b) De Zotti M.; Biondi B.; Formaggio F.; Toniolo C.; Stella L.; Park Y.; Hahm K. S. J. Pept. Sci. 2009, 15, 615. doi: 10.1002/psc.v15:9
[15]	Praveen P.; Tailhades J.; Rosengren K. J.; Liu M.-J.; Wade J. D.; Bathgate R. A. D.; Hossain M. A. ACS Med. Chem. Lett. 2020, 11, 2336. doi: 10.1021/acsmedchemlett.0c00456 pmid: 33214850
[16]	Arbour C. A.; Mendoza L. G.; Stockdill J. L. Org. Biomol. Chem. 2020, 18, 7253. doi: 10.1039/D0OB01417F
[17]	Elashal H. E.; Cohen R. D.; Raj M. Chem. Commun. 2016, 52, 9699. doi: 10.1039/C6CC04245G
[18]	Edwards W. B.; Fields C. G.; Anderson C. J.; Pajeau T. S.; Welch M. J.; Fields G. B. J. Med. Chem. 1994, 37, 3749. pmid: 7966134
[19]	Crawhall J. C.; Elliott D. F. Biochem. J. 1955, 61, 264. doi: 10.1042/bj0610264
[20]	Chen S. H.; Chuang H. Y.; Rajavel C.; Lin Y. K.; Chang S. H.; Tsai P.-C.; Chen H. T.; Sun C. M.; Selvaraj A.; Kao C. L. Adv. Synth. Catal. 2024, 366, 2534. doi: 10.1002/adsc.v366.11
[21]	Lawrenson S. B.; Arav R.; North M. Green Chem. 2017, 19, 1685. doi: 10.1039/C7GC00247E
[22]	Al Musaimi O.; de la Torre B. G.; Albericio F. Green Chem. 2020, 22, 996. doi: 10.1039/C9GC03982A
[23]	Martin V.; Egelund P. H. G.; Johansson H.; Le Quement S. T.; Wojcik F.; Pedersen D. S. RSC Adv. 2020, 10, 42457. doi: 10.1039/D0RA07204D
[24]	Ganesh K. N.; Zhang D.-Q.; Miller S. J.; Rossen K.; Chirik P. J.; Kozlowski M. C.; Zimmerman J. B.; Brooks B. W.; Savage P. E.; Allen D. T.; Voutchkova-Kostal A. M. Organometallics 2021, 40, 1801. doi: 10.1021/acs.organomet.1c00343
[25]	Takahashi D.; Inomata T.; Fukui T. Angew. Chem., Int. Ed. 2017, 56, 7803. doi: 10.1002/anie.201702931 pmid: 28504858
[26]	(a) Martin V.; Jadhav S.; Egelund P. H. G.; Liffert R.; Castro H. J.; Krüger T.; Haselmann K. F.; Le Quement S. T.; Albericio F.; Dettner F.; Lechner C.; Schönleber R.; Pedersen D. S. Green Chem. 2021, 23, 3295. doi: 10.1039/D1GC00603G
	(b) Jadhav S.; Martin V.; Egelund P. H. G.; Castro H. J.; Krüger T.; Richner F.; Quement S. T. L.; Albericio F.; Dettner F.; Lechner C.; Schönleber R.; Pedersen D. S. Green Chem. 2021, 23, 3312. doi: 10.1039/D1GC00604E
	(c) Lopez J.; Pletscher S.; Aemissegger A.; Bucher C.; Gallou F. Org. Process Res. Dev. 2018, 22, 494. doi: 10.1021/acs.oprd.7b00389
	(d) Kumar A.; Alhassan M.; Lopez J.; Albericio F.; de la Torre B. G. ChemSusChem 2020, 13, 5288. doi: 10.1002/cssc.v13.19
